HDPE Pipe Thermofusion Machine SHD450
Packing: Wooden Boxes.
Model NO.: SHD450.
Standard: CE, SGS.
Product Type: Plastic Pipe
Raw Material: HDPE
Type ( For Injection Machine) : Full-Electric Controlled
Kind: Full-Electric Controlled
Type: Plastic Auxiliary Equipment
Item Name: Hydraulic Butt Fusion Welding Machine SHD450
Application and Features:
• Suitable for butt welding of plastic pipes and fittings made of PE, PP and PVDF in a ditch in worksite or workshop.
• Consists of basic frame, hydraulic unit, planing tool, heating plate, support for planing tool & heating plate, and optional parts.
• Removable PTFE coated heating plate with high accurate temperature control system.
• Electric planing tool.
• Be made of lightweight and high strength material: Specially designed with a clamp opening angle of 45° .
• Low starting pressure ensures reliable welding quality of small pipes.
• Changeable welding position enables to weld various fittings more easily.
• High accurate and shockproof pressure meter indicates clearer readings.
• Separate two-channel timer records time in soaking and cooling phases.
On Request Optional Parts:
• Stub end device for short flange.
• Data logger
Pipe size( mm) .: 22.214.171.1240.315.355.400.450
Heating plate max. temp.: 270° C
Temp. deviation in surface( 170~ 250° C) .: < ± 7° C
Pressure adjustable ranges.: 0 – 8Mpa
Working voltage.: 380V, 50Hz
Heating plate power.: 5.38KW
Planing tool power.: 1.5KW
Hydraulic unit power.: 1.5KW
Total Power.: 8.38KW
Packing: Volume.: 3.16 CBM
